Joint surface according to DIN 1809
Suitable for DOOSAN/DAEWOO/HWACHON
Output shaft collet according to DIN 6499
Product Drawings
Product Parameters
| PRODUCT PARAMETER | ||||||||||
| Drawing number | A | B | C | D | E | F | G | H | I | N.W.(KG) |
| BMT45-ST | 88 | 40 | ER16(0.5-10) | 45 | 72.5 | 58 | 58 | 85 | 75 | 3.5 |
| BMT55-ST | 94 | 48 | ER16(0.5-10) | 55 | 72.5 | 64 | 64 | 95 | 85 | 3.8 |
| BMT65-ST | 100 | 48 | ER16(0.5-10) | 65 | 78.5 | 73 | 70 | 105 | 94 | 5.2 |
