45°Turning Centre(Double Spindle Single Turret Single Y-axis) GP-400SY

Product Drawings

ltemS i z eGP-400SY
Working rangeMax.Turning diameter over bedφ580
Max.Turming swing dia.over carriageφ330
Max.Turing diameterφ250(When the X, Y axis and power tool turret are protected as a whole)
Max.Length between both chucks480500
Max.Processing length400430
Max.X/Z axis traveX2 axis230
Y2 axis120
Z2 axis530
Max.Taiistock travel530
Feed screwControl axis6Axis(X+Y+Z+Z3+C1+C2
X2 axis ball-screw3208-C3
(N·m)Recommend the X2 axis motor torque>10
Y2 axis ball-screw3208-C3
(N·m)Recommend the Y2 axis motor torque≥10
Z2 axis ball-screw3208-C3
(N·m)Recommend the Z2 axis motor torque>15
Tailstock ball-screw3208-C3
(N·m)Recommend tallstock motor torque>15
BedBed slant angle45° integral casting bed
Linear quide's span400
Spindle(tpm)Max.spindle speedMAIN:4500 BACK:4500MAIN:4500 BACK:4500
Spindle through-hole diameterMAIN:φ61 BACK:φ56MAIN:φ61 BACK:φ56
Spindle nose sizeMAIN:A2-6 BACK:A2-5MAIN:A2-6 BACK:A2-5
(kW)Recommend the spindle motor powerMAIN:7.5 BACK:5.5MAIN:5.5 BACK:5.5
Hydraulic chuck or collet chuckMAIN:8 INCH BACK:6 INCHMAIN:6 INCH BACK:6 INCH
