45°Turning Centre(Double Spindle Single Turret) GP-400S

Product Drawings

 l t emSizeGP-400S
Working rangMax.Turning diameter over bedφ580
Max.Turning swing dia over cariageφ350
Max.Turing diameterφ250(When the X-axis is protected with a special hydraulic turret.)
Max.Length between both chucks480500
Max.Processing lengtt450480
Max XZ axis taX2 axis230
Z2 axis530
Max.Tallstock travel530
Feed screwControl axis5Axis(X2+Z2+Z3+C1+C2
X2 axis ball-screw3208-C3
(N·m)Recommend the X2 axis motor torque>10
Z2 axis ball-screw3208-C3
(N·m)Recommend the Z2 axis motor torque>15
Tailstock ball-screw3208-C3
(N·m)Recommend talstock motor torque>15
   BedBed slant angle45° Integral cast bed
Linear guide's span400
Spindle(tpm)Max.spindle speedmain spindle:4500              back spindle:4500main spindle:4500              back spindle:4500
Spindle through-hole diametermain spindle:φ61       back spindle:φ56main spindle:φ56        back spindle:φ56
Spindle nose sizemain spindle:A2-5        back spindle:A2-5main spindle:A2-5         back spindle:A2-5
(kW)Recommend the spindle motor powermain spindle:7.5             back spindle:5.5main spindle:5.5             back spindle:5.5
Hydraulic chuck or collet chuckmain spindle:8 inch          back spindle:6 inchmain spindle:6 inch          back spindle:6 inch
