45°Turning Centre(Double Spindle and Turret) GP-400ST-2

Product Drawings

 I t emSizeGP-400ST(Dual electric spindlesA2- 5/A2- 5)
Working rangeMax.Turning diameter over bedφ 580
Max.Turning swing dia.over cariageφ350
Max.Turing diameter   φ250(When the X-axis is protected with a special hydraulic turret.)
Max.Length between both chucks630
Max.Processing length500
Max.X/Z axis traX axis230/230
Zaxis400/530
Max.Tailstock travel530
Feed screwControl axis   7Axis(X1+X2+Z1+Z2+Z3+C1+C2)
X1/X2 axis ball-screw3208-C3
(N·m)Recommend theX1X2 axis motor torque10
Z axis ball-screw3208-C3
(N·m)Recommend the Zaxis motor torque>15
Tailstock ball-screw3208-C3
(N·m)Recommend tailstock motor torque15
BedBed slant angle45° Integral cast bed
Linear guide's span400
PMSM
snie
(rpm)Max.spindle speedmain spindle:5000                 back spindle:5000
Spindle through-hole diametermain spindle:φ56                 back spindle:φ56
Spindle nose sizemain spindle:A2-5               back spindle:A2-5
(kW)Rated powermain spindle:11                    back spindle:11
Hydraulic chuck or collet chuckmain spindle:6 inch              back spindle:6 inch
